Description

CARL TRACK LIGHT

The Carl series offers a sleek range of LED track lights ideal for retail, hospitality and general display applications. Carl offers a versatile range of light head designs, illumination levels and beam angles. With our market leading colour rendering and easy adjustability we confidently recommend Carl as an ideal luminaire to bring out the best in your design.

All fixtures fit a standard three circuit track and adjust through 90° vertical plane and 355° horizontal plane. Options include CCT colour, onboard or on-track driver, glass and honeycomb diffusers, and barn door cut off control.

Also available in surface mount and suspended format.

ST-A092

Source Power: 17W / 21W
System Power: 20W / 24W
Source Lumens: Up to 2944Lm
Delivered Lumens: Up to 2596Lm
Beam Angle:  Narrow/Medium/Wide
Efficacy:  Up to 87Lm/W
Tilt:  90°
Download:  Datasheet
IES Files

ST-A422

Source Power: 17W / 25W
System Power: 20W / 30W
Source Lumens: Up to 3340Lm
Delivered Lumens: Up to 2916Lm
Beam Angle:  Narrow/Medium/Wide
Efficacy:  Up to 99Lm/W
Tilt:  90°
Download:  Datasheet
IES Files

ST-A849

Source Power: 17W / 25W
System Power: 20W / 30W
Source Lumens: Up to 3240Lm
Delivered Lumens: Up to 2896Lm
Beam Angle:  Narrow/Medium/Wide
Efficacy:  Up to 97Lm/W
Tilt:  90°
Download:  Datasheet
IES Files

ST-A249

Source Power: 17W / 25W / 32W
System Power: 20W / 30W / 37W
Source Lumens: Up to 3850Lm
Delivered Lumens: Up to 3092Lm
Beam Angle:  Narrow/Medium/Wide
Efficacy:  Up to 80Lm/W
Tilt:  90°
Download:  Datasheet
IES Files

ST-A593

Source Power: 17W / 25W / 32W
System Power: 20W / 30W / 37W
Source Lumens: Up to 3850Lm
Delivered Lumens: Up to 3443Lm
Beam Angle:  Narrow/Medium/Wide
Efficacy:  Up to 99Lm/W
Tilt:  90°
Download:  Datasheet
IES Files

ST-A849

Source Power: 17W / 25W / 32W / 36W
System Power: 20W / 30W / 37W / 42W
Source Lumens: Up to 4630Lm
Delivered Lumens: Up to 4197Lm
Beam Angle:  Very Narrow/Narrow/
Medium/Wide
Efficacy:  Up to 100Lm/W
Tilt:  90°
Download:  Datasheet
IES Files
Finish Black/White Material Aluminium
IP Rating IP20 CCT  3000K/4000K
CRI >80/>90 Voltage 230V, 50Hz
Lifetime >50,000 hours Dimming Available on request
